Details
- •Low-voltage industrial components
- •Power circuit-breaker for trafo/generator/installation protection
- •1 KOM
- •ABB
Technical specifications
Rated permanent current Iu4000A
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz100kA
Overload release current setting1600.0 - 4000A
Rated voltage690 - 690V
Number of auxiliary contacts as change-over contact4
Device constructionBuilt-in device slide-in technique (withdrawable)
Type of electrical connection of main circuitConnection at separate chassis part
Adjustment range short-term delayed short-circuit release2400.0 - 40000A
Adjustment range undelayed short-circuit release6000.0 - 60000A
Integrated earth fault protectionYes
With switched-off indicatorYes
Power loss544W
Number of auxiliary contacts as normally open contact0
With integrated under voltage releaseNo
Suitable for DIN rail (top hat rail) mountingNo
DIN rail (top hat rail) mounting optionalNo
Number of auxiliary contacts as normally closed contact0
Number of poles4
Complete device with protection unitYes
Position of connection for main current circuitConnection at separate chassis part
Motor drive optionalYes
Type of control elementPush button
Degree of protection (IP)IP30
Motor drive integratedNo
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
1SDA129021R1 | E6.3H4000EkipAwareLSIG4pWMP
