Details
- •Low-voltage industrial components
- •Contactor relay
- •1 KOM
- •ABB
Technical specifications
Rated control supply voltage Us at AC 50HZ- - -V
Rated operation current4A
Rated operation current Ie, 400 V3A
Mounting methodDIN rail
With LED indicationNo
Rated control supply voltage Us at AC 60HZ- - -V
InterfaceNo
Number of auxiliary contacts as normally closed contact, delayed switching0
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact, leading0
Rated control supply voltage Us at DC42 - 42V
Voltage type for actuatingDC
Number of auxiliary contacts as change-over contact0
Number of auxiliary contacts as normally open contact4
Suitable for manual operationNo
Operating voltage at AC 50 Hz690 - 690V
Operating voltage at AC 60 Hz690 - 690V
Rated switch current4A
Operating voltage at DC250 - 250V
Voltage type (operating voltage)DC
Height57.5mm
Depth46.5mm
Connection type auxiliary circuitScrew connection
Width52.5mm
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user
GJH1213001R0402 | KC6-40E-02
Why Register?
- View wholesale prices with discounts
- Real-time stock availability
- Access invoices and dispatch notes
- Order history and frequently ordered items
- Exclusive B2B offers
and much more...
Details
- Low-voltage industrial components
- Contactor relay
- 1 KOM
- ABB
DetailsTechnical specifications
Technical specifications
Rated control supply voltage Us at AC 50HZ
- .. -V
Rated operation current
4A
Rated operation current Ie, 400 V
3A
Mounting method
DIN rail
With LED indication
Rated control supply voltage Us at AC 60HZ
- .. -V
Interface
Number of auxiliary contacts as normally closed contact, delayed switching
0
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as normally open contact, leading
0
Rated control supply voltage Us at DC
42 .. 42V
Voltage type for actuating
DC
Number of auxiliary contacts as change-over contact
0
Number of auxiliary contacts as normally open contact
4
Suitable for manual operation
Operating voltage at AC 50 Hz
690 .. 690V
Operating voltage at AC 60 Hz
690 .. 690V
Rated switch current
4A
Operating voltage at DC
250 .. 250V
Voltage type (operating voltage)
DC
Height
57.5mm
Depth
46.5mm
Connection type auxiliary circuit
Screw connection
Width
52.5mm
